InkBags repairs HP FI-1000 and HP PageWide industrial printheads. Blocked nozzles, dried ink, contaminated ink paths and air-lock after ink starvation are recoverable in a large share of cases; a die segment that is electrically dead or a nozzle plate that is physically damaged is not, and that head has to be replaced. We work out which case you have from a nozzle test print, before anything is dismantled or quoted.
Why a failed sector stops production
The HP FI-1000 is a single 297 mm page-wide array. There is no carriage motion to average out a fault, so when one die segment stops firing you get a continuous band of missing print in exactly the same place on every piece that comes off the machine.
That is why an FI-1000 nozzle fault is a production stoppage rather than a quality complaint — and why the diagnosis matters more than the repair.
Print width
297 mm / 11.7 in, one fixed page-wide head
Resolution
up to 1200 × 1200 dpi
Max speed
up to 457 mm/s (≈27 m/min)
Ink
HP pigment, CMYK
Symptom, cause and whether it recovers
The pattern on the nozzle test print is what separates a cleanable head from a dead one. This is the table we work from.
| What you see | What it usually means | Outcome |
|---|---|---|
| A solid white band down the web, same place on every copy | A whole die segment has stopped firing | Recoverable if the cause is dried ink or blockage; not recoverable if the segment is electrically dead |
| Fine missing lines that partly return after a purge | Nozzles blocked by dried ink after idle time | Usually recoverable |
| Nozzles recover, then drop out again within a short run | Restriction upstream of the head — filter, line or supply pressure | Recoverable, and replacing the head would not have fixed it |
| One colour channel weak or missing | Blocked feed or partially blocked die area on that channel | Usually recoverable |
| Density falling off across the width after long production | Nozzle plate contamination, worn wiper or failing capping | Recoverable — but the capping and wiping station has to be serviced too |
| Head errors or refusal to come ready after running dry | Air drawn into the head during an ink starvation event | Often recoverable by controlled purging and re-priming |
| Scratches or visible damage on the nozzle plate | Physical contact damage | Not recoverable — replacement head |
Machines we repair printheads for
The FI-1000 is an OEM print engine sold under many brands, so the badge on the front rarely tells you what is inside. Each page covers what actually fails on that machine.
HP FI-1000 based machines
HP
HP FI-1000 printhead repair
The 297 mm HP Fixed Imager 1000 printhead itself — the part that fails in every FI-1000 based machine, whatever badge is on the front.
Boxmaking Machinery GmbH
Boxmaking Machinery BM300 printhead repair
Single-pass packaging press built directly around the HP FI-1000, printing bags, boxes, mailers and envelopes at up to 27 m/min.
Printware / iJetColor
Printware iJetColor Pro 1175P printhead repair
High-speed envelope and direct-mail press built on the HP FI-1000, launched by Printware in 2020.
Printware / iJetColor
Printware iJetColor Pro PXG printhead repair
Packaging-oriented member of the iJetColor Pro series using the HP FI-1000 fixed imager, launched at PackExpo 2021.
HSA USA
HSA SPD-1175 printhead repair
Single-pass digital printing system built on the HP FI-1000 for inline coding, marking and packaging print.
TICAB Print
TICAB Print TPS printhead repair
TICAB industrial printing system in the HP FI-1000 class, used for packaging and industrial substrate printing.
HP PageWide based machines
NeuraLabel / Neuralog
Neuralog NeuraLabel 300x printhead repair
HP PageWide based high-speed label printer — same HP thermal inkjet family as the FI-1000, different engine and width.
HP
HP PageWide XL printhead repair
HP’s wide-format PageWide platform for technical documents, GIS and large-format production — serviced and supplied by InkBags alongside FI-1000.
Machine not listed? Send us the model and we will identify the printhead for you.
How a repair job runs
- Send a nozzle test print. Photograph or scan the nozzle test and describe what the machine was doing when the fault appeared. Do not keep running recovery cycles first — repeated aggressive purging on a head that has already dried out can turn a recoverable fault into a replacement.
- Get a diagnosis. We identify the failure pattern — sector, row or random dropout — and tell you whether recovery is realistic, before anything is dismantled.
- Approve scope and price. You get the work scope and the price up front, including whether the ink delivery system needs service as well. No open-ended billing.
- Service, or replace. We recover the head where it can be recovered and supply a replacement where it cannot. Either way the machine goes back into production.
Printhead repair FAQ
Can an HP FI-1000 printhead be repaired?
Often, yes. Blocked nozzles, dried ink, contaminated ink paths, clogged filters and air-lock after ink starvation are recoverable in a large share of cases. Physical or electrical damage to a die segment is not recoverable by any process, and that head has to be replaced. Which case you have is determined from a nozzle test print before any work is quoted.
How much does HP FI-1000 printhead repair cost?
Cost depends on the failure mode and on whether the ink delivery system needs service as well, so it is quoted per case rather than published as a fixed price. Send a nozzle test print and a short description of what the machine was doing when the fault appeared, and you get a scope and a price before anything is dismantled.
What does a failed sector on an FI-1000 nozzle test look like?
A continuous band of missing print running along the direction of travel, in exactly the same position on every copy. Because the FI-1000 is a fixed page-wide head, it cannot print around the fault the way a scanning carriage printer can, so the defect appears on every piece.
Do I have to send the whole printer for printhead repair?
No. In most cases only the printhead assembly is shipped. Tell us the machine and we confirm exactly what has to come out and how to pack it so the head is not damaged in transit.
How long does printhead repair take?
Turnaround depends on the failure mode and on parts availability. We give a realistic timeline when we quote, before you take the machine apart, rather than after.
Should I repair or replace an FI-1000 printhead?
Repair is worth it when the fault is blockage, contamination or air-lock, because those recover. Replacement is the only option when a die segment is electrically dead or the nozzle plate is physically damaged. We tell you which one you have rather than selling the more expensive answer by default.
Which printers use the HP FI-1000 printhead?
The FI-1000 is an OEM print engine that HP supplies to machine builders, so it appears under several brands — including the Boxmaking Machinery BM300, the Printware iJetColor Pro series, the HSA SPD-1175 and TICAB industrial systems.
Can you repair HP PageWide printheads too?
Yes. We service HP PageWide printheads used in industrial label printers such as the NeuraLabel 300x, and HP PageWide XL wide-format machines. The parts and procedures differ from FI-1000, so tell us the exact model.
Send a nozzle test print, get a straight answer
We tell you the likely root cause, whether it is recoverable, and what it costs — including when it is not worth spending the money.
